XSCAN C series
① 2D/3D Hybrid Inspection System with Automation Technology
② Precise results using high-speed OCT technology
③ Built for user convenience
– S/W, Table Size, etc. can be customized according to users and applications.
Description
Specification
Description
[pafe-template id=”1967″]
Specification
XSCAN-7650C/H | XSCAN-8160 | XSCAN8160W | XSCAN8225C | ||
X-RAY Tube | 150KV/75W | 160KV/400W | 225KV/450KV/450W(S)&900W(L) | ||
Tube type/Focal spot | Closed type / 5μm | Closed type / 0.4mm | Closed type / 0.4mm | ||
X-ray Detector | 5″ or 8″ or 12″ or 16″ Flat Panel Detector(FPD) or 9″ Image Intensifier | ||||
Inspection Area | Ø300 / Ø500 x 700 (H) | Ø500 x 1000mm (H) | Ø300 / Ø500 x 600mm (H) | ||
Axis control | Basic 5 Axis:X,Y,Z,T,R | ||||
Dimension | 2100 x 1800 x 2100mm | 2390 x 1810 x 1960mm | 2604 x 2045 x 2109mm | 2560 x 1980 x 2080mm | |
Weight | 3000kg | 4000kg | |||
Utility | AC 220V, Single phase, 50/60Hz | ||||
Application | Die-casting, Automotive parts, Batteries, and other large products |
